אל פסק EATON 9E-3000i

'

General

Topology

Online double conversion

Configuration

Tower

Part Number

9E3000I

Rating (VA/Watts)

3000/2400

Dimensions (H x W x D, mm)

399 x 330 x 190

Weight (kg)

24.2

Warranty

2 years

Electrical Input

Connection

(1) IEC-320-C20

Input Voltage Range

176-300V without derating (up to 100-300V with derating)

Nominal Voltage

208/220/230/240V

Frequency

50/60 Hz autoselection

Frequency Range

40-70 Hz

Electrical Output

Voltages

208V*/220V/230V/240V ±1%

Voltage THD

<2% for 100% linear load

Outlets

(6) IEC-320-C13

(1) IEC-320-C19

Overload Capacity

105%-130% : 60s, 130%-150% : 10s,>150% : ≥ 300ms

Efficiency (Normal Mode)

Up to 91% in Online mode

Output Frequency

50/60 Hz autoselect

Communications

Communication Ports

1 USB port + 1 RS232 serial port (USB and RS232 ports cannot be used simultaneously)

Communication Slot

1 slot for Network-M2, ModBus-MS or Relay-MS cards

Power Management Software

Intelligent Power Editions

Environmental & Standards

Audible Noise

<37 dB @ typical load

Operating Temperature

0 to 40°C

Safety markings

IEC/EN 62040-1

EMC Markings

IEC/EN 62040 -2

Approvals

CE, CB report (TUV)
