שרת NAS Synology RS3617xs+ 12BAY

CPU

CPU Model Intel Atom C3538

CPU Architecture 64-bit

CPU Frequency Quad Core 2.1 GHz

Hardware Encryption Engine (AES-NI)

Memory

System Memory 4 GB DDR4

Memory Module Pre-installed 4 GB (4 GB x 1)

Total Memory Slots 4

Memory Expandable up to 64 GB (16 GB x 4)

Notes

Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.

Storage

Drive Bays 12

Maximum Drive Bays with Expansion Unit 24

Compatible Drive Type* (See all supported drives) 3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

Maximum Internal Raw Capacity 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)

Maximum Raw Capacity with Expansion Units 384 TB (192 TB + 16 TB drive x 12) (Capacity may vary by RAID types)

Maximum Single Volume Size* 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)

Hot Swappable Drive

Notes

"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)

Each internal volume (may consist of multiple drives) is expandble up to 108TB (with memory less than 32GB) or 200TB (with memory equal to or greater than 32GB).

External Ports

RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)

USB 3.0 Port 2

Expansion Port 1

PCIe

PCIe Expansion 1 x Gen3 x8 slot (black, x4 link)

Add-In-Card Support PCIe Network Interface Card (Learn more)

M2D18 – Dual M.2 SATA/NVMe SSD adapter card for SSD cache

File System

Internal Drives Btrfs

EXT4

External Drives Btrfs

EXT4

EXT3

FAT

NTFS

HFS+

exFAT*

Notes

exFAT Access is purchased separately in Package Center.

Appearance

Form Factor (RU) 2U

Size (Height x Width x Depth) 88 mm x 482 mm x 696 mm

88 mm x 482 mm x 724 mm (for RP model)

Weight 13.22 kg

13.85 kg (for RP model)

Rack Installation Support* 4-post 19" rack (Synology Rail Kit – RKS1317)

Notes

The rail kit is sold separately

Others

System Fan 80 mm x 80 mm x 4 pcs

80 mm x 80 mm x 4 pcs (for RP model)

Fan Speed Mode Full-Speed Mode

Cool Mode

Quiet Mode

Easy Replacement System Fan

Power Recovery

Noise Level* 54 dB(A)

54.1 dB(A) (for RP model)

Scheduled Power On / Off

Wake on LAN / WAN

Power Supply Unit / Adapter 500 W

Redundant Power Supply yes (for RP model)

AC Input Power Voltage 100 V to 240 V AC

Power Frequency 50/60 Hz, Single Phase

Power Consumption* 109 W (Access)

52.4 W (HDD Hibernation)

119.6 W (Access) (for RP model)

55.9 W (HDD Hibernation) (for RP model)

British Thermal Unit 371.92 BTU/hr (Access)

178.8 BTU/hr (HDD Hibernation)

408.09 BTU/hr (Access) (for RP model)

190.74 BTU/hr (HDD Hibernation) (for RP model)

Notes

Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).

Support for Wake on WAN needs switch and routers which recognize Magic Packet.

Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75?C; Humidity: 58.2-61.8%

Temperature

Operating Temperature 5°C to 35°C (40°F to 95°F)

Storage Temperature -20°C to 60°C (-5°F to 140°F)

Relative Humidity 5% to 95% RH

Certification

EAC

VCCI
